Modular On-line double conversion UPS and modules 14 and 30 kVA
Flexibility, availability and reliability in superior electrical protection
Salicru’s SLC ADAPT2 A series consists of modular On-line double conversion uninterruptible power supply (UPS) solutions with DSP control and three-level IGBT inverter technology.
Flexibility: It enables solutions to be configured from 14 kVA to 900 kVA, thanks to the range of modules available (14 and 30 kVA), different configurable systems (8, 10 or 12 modules) and the parallel/redundant option of up to three 300 kVA systems. It also provides increased protection as needs grow - pay as you grow - thereby improving total cost of ownership (TCO).
Availability: Its hot-swap modules can be added or replaced during operation, thereby improving mean time to repair (MTTR) and reducing maintenance costs. In addition, the system’s remote management, which can be integrated into any platform, also facilitates operation. And the extensive back-up options available, along with intelligent battery charging, ensure continuous operation of the protected critical loads.
Reliability: Its DSP control, based on three-level PWM technology, improves response effectiveness and, along with shared load redundancy, significantly extends the mean time between failures (MTBF).
Characteristics
Applications
Redundant protection for critical applications
Data centres with all capacities, IT infrastructures, modular and virtualised data centres and applications for critical processes are some of the services that require high-level electrical protection to ensure reliable, continuous and high-quality operation, such as that provided by Salicru's SLC ADAPT2 A series systems.
Performances
On-line double-conversion technology
Output power factor PF=1
Parallel cabinet system
Touch screen
RS-232, RS-485, relay and USB interface
Smart slot for SNMP and relays
Available backup extensions
Eco-mode operation
Maintenance bypass
Separate bypass input
Smart-efficiency mode
Hot-pluggable and swappable plug & play modules
Display
Display consisting of operation keys, status LEDs and touch screen detailing all functions, measurements and alarms.
Power modules
14, 20 and 30 kVA power modules, with on-line double conversion technology, compact format from 2U to 4U in height. Consists of a rectifier with PFC (power factor correction), 3-stage inverter type NPC, intelligent battery charger and DSP control for each module. Hot-swap and hot-plug functions for greater flexibility and better maintenance.
Options
- Extended relays and SNMP/Nimbus adapter.
- Extended back-up times.
- Kit for parallel systems.
- Frequency converter operation.
Technical support and service
- Pre-sales and after-sales advice.
- Start-up. (1)
- Technical support by telephone.
- Preventive/corrective services.
- Maintenance contracts. (1)
- Training courses.
Connections
- Manual bypass.
- Start-up from batteries (Cold Start).
- LCD display.
- Bypass module.
- Dry contacts.
- Extended relays and SNMP/Nimbus slot.
- RS-232, RS-485 and USB interfaces.
- Power modules.
Models
Showing 1 - 5 of 5 products
SLC-#/8 ADAPT2 112 A
Module power (VA / W):
14000 / 14000
Input voltage (V):
3x 208 / 220 V (3F + N)
Output voltage (V):
3x 208 / 220 V (3F + N)
System power (VA/W):
112000 / 112000
SLC-#/12 ADAPT2 168 A
Module power (VA / W):
14000 / 14000
Input voltage (V):
3x 208 / 220 V (3F + N)
Output voltage (V):
3x 208 / 220 V (3F + N)
System power (VA/W):
168000 / 168000
SLC-#20-ADAPT A 120
Module power (VA / W):
20.000 / 16.000
Input voltage (V):
3x 208 / 220 V (3F + N)
Output voltage (V):
3x 208 / 220 V (3F + N)
System power (VA/W):
120000 / 96000
SLC-#20-ADAPT A 200
Module power (VA / W):
20.000 / 16.000
Input voltage (V):
3x 208 / 220 V (3F + N)
Output voltage (V):
3x 208 / 220 V (3F + N)
System power (VA/W):
200000 / 160000
SLC-#/10 ADAPT2 300 A
Module power (VA / W):
30000 / 30000
Input voltage (V):
3x 208 / 220 V (3F + N)
Output voltage (V):
3x 208 / 220 V (3F + N)
System power (VA/W):
300000 / 300000
Showing 1 - 5 of 5 products
