RE3
RE3
Electronic voltage stabilisers from 300 VA to 150 kVA
The fastest and the most accurate electronic regulation system of the market
In today's electronic environment, saturated and highly unstable, where fluctuations in the power supply voltage are more than frequent, voltage stabilisers play a very important role in guaranteeing stable voltage to loads more sensitive to such variations.
The Salicru RE series of electronic stabilisers, based on a completely static structure of high efficiency, fast reply speed and excellent output precision, are made in single phase or three phase configuration and in a range of powers from 300 VA to 150kVA.
The three-phase units are conceived with a completely phase-independent regulation in order to avoid possible regulation problems due to imbalance in the loads. Moreover, the units include a static bypass to guarantee the power supply in the event of a possible fault.
Characteristics
Applications
Assured industrial processes
Many are the industrial processes where voltage stability is essential: from a wide range of applications where the numerical control processors and automatons are entrusted with guaranteeing the final result, up to all kinds of calculation centres, computer peripherals, transmission and communications equipment, laboratory equipment, etc.
Performances
Output power factor PF=1
Control panel LCD display and keypad
Output precision better than ±2%
High response speed
Regulation range +/-15%
Performance >97%
Display
- LCD 2x16 characters.
- Navigation keys.
- LEDs (alarm, bypass, normal operation and communications).
Technical support and service
- Pre-sale and after sales advisory service.
- Numerous maintenance and remote maintenance options.
Options
- Relay interface.
- Manual maintenance bypass.(1)
- Protection of high-low voltage with manual or automatic reset (output voltage disconection when out of range).
- Isolation transformer (T).
- Ultra-isolation transformer (NS).
- Current transformers for measures of current, power (kVA / kW) and power factor.
- Overload protection. (1)
- Telemanagement card. (1)
- Extended communications module. (1)
- Extended ambient operating temperature from -20ºC.
- Input & output circuit breaker.
Models
RE-1009-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
1000 / 1000
Transformador separador (>40dB):
-
RE-2009-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
2000 / 2000
Transformador separador (>40dB):
-
RE-3009-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
3000 / 3000
Transformador separador (>40dB):
-
RE-4509-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
4500 / 4500
Transformador separador (>40dB):
-
RE3 M 6-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
6000 / 6000
Transformador separador (>40dB):
-
RE3 M 9-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
9000 / 9000
Transformador separador (>40dB):
-
RE3 M 12-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
12000 / 12000
Transformador separador (>40dB):
-
RE3 M 15-2
Regulation margin:
±15% (2)
Output voltage (V):
220 V, 230 V, 240 V
System power (VA/W):
15000 / 15000
Transformador separador (>40dB):
-
RET 3-4
Regulation margin:
±15% (2)
Output voltage (V):
3 x 380 V, 3 x 400 V, 3 x 415 V (3F + N)
System power (VA/W):
3000 / 3000
Transformador separador (>40dB):
-
RET 6-4
Regulation margin:
±15% (2)
Output voltage (V):
3 x 380 V, 3 x 400 V, 3 x 415 V (3F + N)
System power (VA/W):
6000 / 6000
Transformador separador (>40dB):
-
Request information about RE3
