KIT NE+ 3,5-2-LCD
Specifications
Technical specifications
TECHNOLOGY
Bidirectional ‘Buck’ converter with IGBTs, electronic, static and transformerles
INPUT
Regulation range
+ 25% / - 7% nominal voltage; + 25% / - 17% saving voltage HPSV; + 25% / - 10% saving voltage MV/MH
Rated frequency
40 ÷ 65 Hz
Module protection
Input/output fuses / electronic for temperature, overload
Protection for phase
Fuse
OUTPUT
Rated voltage
Adjustable 215 V to 230 V (220 V as standard)
Accuracy
Better than ± 1%
Soft start voltage
Preselectable (1) and adjustable
Saving voltage
Adjustable 180 V to 210 V
Speed ramp setting
From 1 V/minute to 6 V/minute
Response time
< 40 ms
Regulation
Linear and independent per phase
Performance
96% ÷ 98%
Phase unbalancing
100% permissible
Permissible overload
Through LCD panel or via telemanagement card communication
Admissible overloads
150% for 30 seconds; 120% for > 1 minute
BYPASS
Type
No break
Features
Automatic, reversible, independent per phase, independent operating, input for manual activation
Activation criteria
Overtemperature, overload, fault, output fault, manual activation
Rearm
Automatic by alarm cancelling. Quantity of retries: 5; time between retries: 2 minutes
COMMUNICATION
Ports
RS-232 and RS-485 (2)
GENERAL
Operating temperature
– 20º C ÷ + 55º C (3)
Relative humidity
Up to 95%, non-condensing
Maxium operating altitude
2,400 m.a.s.l.
Acoustic noise at 1 metre
<48 dBA (with typical load)
Mean time between failures (MTBF)
60,000 hours
Mean time to repair (MTTR)
30 minutes
STANDARDS
Safety
UNE AENOR EA 0032:2007
Electromagnetic compatibility (EMC)
IEC 62041
Operation
UNE AENOR EA 0033:2007
Corporate cerification
ISO 9001, ISO 14001, ISO 45001
DIMENSIONS
Depth (mm)
172
Width (mm)
172
Height (mm)
310
WEIGHT
Weight (kg)
8
(1) Depending on type of lamp
(2) Optional
(3) 4% power derating per each degree over 45ºC
